Frequency inverter type FXDM32AME

☆☆☆☆☆ ( 0 rates ) 193
Price : Call

Code: #23124

Supplier: Ziehl Abegg AG

Frequency inverters are ideal for use in the energy efficient control of all types of motors. ZIEHL-ABEGG supplies frequency inverters that are perfectly matched to our customers' applications. The main focus is on ventilation applications, with a special emphasis on ease of handling and operation.

rightMORE INFORMATION

  • The Fcontrol frequency inverters provide special advantages. Fcontrols have an all pole effective sine filter integrated which provides sinusoidal output voltage that is comparable with the standard mains. That means the frequency inverter enables reliable, demand-oriented and energy-saving control of asynchronous motors (external rotor motors, IEC standard motors) without having to take measures into consideration required by standard frequency inverters.

  • Integrated all pole effective sine filter
    Phase to phase and phase to grounded conductor which means sinusoidal output voltage. Measures typical for frequency inverters such as shielded motor feed lines are not required.
    LC-multifunction display with plain text:
    Various menu languages can be selected
    Simple commissioning through operating modes:
    Typical operating modes, e.g. for air-conditioning, refrigeration or ventilation technology can be selected.
    Easy to program:
    Typical settings can be made: e.g., default a minimum speed, limit the maximum speed, inverting and limits. Setting, e.g. for 2-stage mode
    2 analogue inputs for sensors or setpoint signals:
    Analogue input E1 and E2: Setting through operating modes or manually programmable, e.g. 0-10 V, 0-20 mA, 4-20 mA
    Analogue input E2: programmable, e.g. comparison to Sensor 1, difference to Sensor 1, average calculation, setpoint input, setpoint adjustment (e.g. dependent on outdoor temperature)
    Two digital inputs. D2 and D1:
    Programmable, e.g. enable, switchover Setpoint 2 or 1 switchover control or manual operation, switchover E2, or E2, reverse control function, limit output, display of external fault, reset, reverse the rotary direction
    2, analogue output A1:
    Setting through operating modes or manually programmable, e.g., output signal proportional modulation, output signal proportional input signal, invertible, 10 V constant voltage, group control
    10 digital outputs (relays) K1 and K2:
    Setting through operating modes or manual programming, e.g. operating status, limits, external fault on digital input, enabling external devices, e.g. heating, dampers, group control of fans, etc.
    Integrated motor protection function:
    Connection facility for PTC thermistors or alternatively thermostats (TB or TP).
    Interface RS485 MODBUS RTU:
    Integration into bus system
    Setting protection / memory for settings:
    Enable settings protection from unauthorised access, restore implemented settings
    Event memory:
    Query events that have occurred, operating times, etc.
    Standard conformity
    Interference emission according to EN 61000-6-3 (domestic)
    Interference immunity according to EN 61000-6-2 (industrial)

  • - Operation without shielded motor feed lines
    - The line length is not restricted by Fcontrol
    - Operation without electromagnetic motor noises (ideal for noise sensitive areas)
    - No risk to motors (they do not have to be frequency inverter compatible) since they are supplied with sinusoidal voltage that corresponds to the line voltage.
